Price: $159.99
(as of Oct 20, 2024 15:34:46 UTC – Details)
Product Description
Min. Illumination :
0.0007 lux @ F1.6 (Color, 30IRE) 0.0004 lux @ F1.6 (B/W, 30IRE) 0 lux (Illuminator on)
Audio Input : 1 channel (RCA port)
Audio Output : 1 channel (RCA port)
Alarm Input : 1 channel in: wet contact, 5mA 3V–5V DC
Alarm Output : 1 channel out: wet contact, 300mA 12V DC
Support Animal Detection Firmware Update.
With deep learning algorithm, it supports: video metadata, smartsound detection, IVS, face detection, smart object detection, andpeople counting, etc.
IVS (Perimeter Protection) ：Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection, people gathering, and parking detection .Smart Object Detection ：Smart abandoned object; smart missing object .SMD 3.0 ：Less false alarm, longer detection distance .AcuPick : Uses deep learning algorithms and works with back-end devices to accurately match targets, such as people and motor vehicles, and search through live and recorded videos to quickly locate targets.Face Detection ：Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attributes extraction including 6 attributes and 8 expressions; face snapshot set as face, one-inch photo or custom; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting. People Counting ：Tripwire people counting, generating and exporting report (day/week/month/year); people counting in area and queue management; generating and exporting report (day/week/month); 4 rules can be set for tripwire, people counting in area and queue management. Smart Search ：Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos Video Metadata Heat Map Smart Sound Detection
Installation
Dimension
Following figures are for reference only, and the actual product shall prevail.
(Unit: mm [in])99.1 mm × Φ121.9 mm (3.90″ × Φ4.80″)Net Weight :500 g (1.10 lb) Gross Weight : 770 g (1.70 lb)
SD Card Slot and Hard Reset Button
(Optional) Installing the SD Card : Pull the power plug off before installing or removing the SD card.Press and hold the RESET button for 10 s to reset the camera.Please do this when camera is powered on.
Installation Direction
Make sure the mounting surface is strong enough to hold at least three times of the weight of the device and bracket.
Structure
Casing MaterialInner core: MetalCover: MetalDecoration ring: PlasticQuick install mounting plate: Metal
Installation Methods
Optional Accessories（Bracket needs to be purchased separately）：
Accessories:
PFA130-E Water-proof Junction BoxPFB205W-E Wall Mount BracketPFA152-E Pole Mount BracketPFA109 Mount adapterPFB220C Ceiling Mount Bracket
Packing List:
Network Camera × 1Mounting Plate × 1Screw Package × 1Waterproof Connector × 1Quick Start Guide × 1QR Code × 1Positioning Map × 1
For firmware updates, please download the “User Manual” in the “Product guides and documents” section. Click the button on the first page to download.
Add to Cart
Add to Cart
Add to Cart
Add to Cart
Add to Cart
Add to Cart
Customer Reviews
4.4 out of 5 stars
129
3.8 out of 5 stars
16
4.4 out of 5 stars
58
4.7 out of 5 stars
70
—
4.8 out of 5 stars
7
Price
$194.99$194.99 $239.99$239.99 $79.99$79.99 $19.99$19.99 $24.99$24.99 $19.99$19.99
Type
IP Turret Camera IP Turret Camera IP Turret Camera Junction Box Wall Mount Pole Mount
Pixel
4MP 4K 8MP 4MP Water-proof
Image Sensor
1/1.8″ CMOS 1/1.8″ CMOS 1/2.9″ CMOS
Illuminator
2 (IR LED) 2 (IR LED) 1 (IR LED)
Lens
2.7 mm–12 mm Motorized vari-focal Lens 2.7 mm–12 mm Motorized vari-focal Lens 2.8 mm; 3.6 mm Fixed Lens
Field of View
H: 115°–47°; V: 62°–27°; D: 137°–54° H: 113°–47°; V: 60°–26°; D: 133°–53° 2.8 mm: H: 95°; V: 52°; D: 114° / 3.6 mm: H: 78°; V: 41°; D: 94°
Smart AI
IVS (Perimeter Protection)，Smart Object Detection，SMD 3.0，AcuPick，AI SSA，Face Detection，People Counting，Heat Map，Video Metadata，Smart Search. EPTZ, IVS (Perimeter Protection)，Smart Object Detection，SMD 3.0，AcuPick，AI SSA，Face Detection，People Counting，Heat Map，Video Metadata，Smart Search. IVS (Perimeter Protection)，SMD Plus，Smart Search.
Audio
Built-in MIC Built-in MIC Built-in MIC
Protection
IP67 IP67 IP67
.
Support Animal Detection Firmware Update. Support Animal Detection Firmware Update.
Support Animal Detection Firmware Update.
4-MP 1/1.8″ CMOS image sensor, low luminance, and high definitionimage. Outputs max. 4 MP (2688×1520) @25/30fps .
Intelligence :IVS (Perimeter Protection),Smart Object Detection ,SMD 3.0 ,AI SSA , AcuPick ,Face Detection ,People Counting ,Heat ,Video Metadata ,Smart Search ,Smart Sound Detection ,Alarm Event .
Built-in IR LED, and the max. illumination distance is 50m(164.04 ft)(IR) ; ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding afterfilter, flexible coding, applicable to various bandwidth and storageenvironments.
With deep learning algorithm, it supports: video metadata, smartsound detection, IVS, face detection, smart object detection, andpeople counting, etc.
Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SDcard, built-in MIC.
